Pump Type

Bore Pumps

Bore Pumps draw groundwater from bores and deep wells for irrigation, livestock watering and household supply. Explore submersible options from Grundfos, Lowara, Franklin Electric and Pentair. Our team helps you choose the right pump for your depth, flow and pressure needs.

Benefits of shopping with us

Same-day delivery*
National shipping
Friendly, professional advice
Tailored solutions
Australian owned

Browse our bore pump range

Sort by
SP1A-57 1.5kW 380-415V 50Hz
Direct Shipping
Grundfos
SP1A-57 1.5kW 380-415V 50Hz
$7,665.90
$6,305.59
SP2A-28 1.5kW 1x240V 50Hz MS402 / CSCR
Direct Shipping
Grundfos
SP2A-28 1.5kW 1x240V 50Hz MS402 / CSCR
$2,821.07
$2,410.49
SP2A-13 0.55kW 380-415V 50Hz
Direct Shipping
Grundfos
SP2A-13 0.55kW 380-415V 50Hz
$2,027.30
$1,667.56
SP2A-48 2.2KW 415V 50HZ
Direct Shipping
Grundfos
SP2A-48 2.2KW 415V 50HZ
$6,454.80
$5,309.39
SP2A-28 1.5kW 380-415V 50Hz
Direct Shipping
Grundfos
SP2A-28 1.5kW 380-415V 50Hz
$2,845.70
$2,340.73
SP2A-33 1.5kW 1x240V 50Hz MS402 / CSCR
Direct Shipping
Grundfos
SP2A-33 1.5kW 1x240V 50Hz MS402 / CSCR
$2,974.65
$2,538.79
SQ 3-80 N 1.55kW 200-240V 50/60Hz+T/Kit
Direct Shipping
Grundfos
SQ 3-80 N 1.55kW 200-240V 50/60Hz+T/Kit
$2,610.30
$2,147.10
4" FPS 4400 High Capacity Submersible Pump FPS-9A-16 - 2.2KW - 9 m3/h - 150 LPM - PMA WITH 1PH CONTROL BOX
Available to Order
Franklin
4" FPS 4400 High Capacity Submersible Pump FPS-9A-16 - 2.2KW - 9 m3/h - 150 LPM - PMA WITH 1PH CONTROL BOX
$4,713.50
$3,760.24
SP1A-42 1.1kW 1x240V 50Hz MS402 / CSCR
Direct Shipping
Grundfos
SP1A-42 1.1kW 1x240V 50Hz MS402 / CSCR
$3,760.03
$3,209.09
SQ 3-55 N 3" Borehole Submersible pump with a 1.15kw 240 V motor
Direct Shipping
Grundfos
SQ 3-55 N 3" Borehole Submersible pump with a 1.15kw 240 V motor
$1,954.70
$1,607.84
4" FPS 9A-16 4400 High Capacity Submersible PUMP & 3PH MOTOR ASSEMBLY
Available to Order
Franklin
4" FPS 9A-16 4400 High Capacity Submersible PUMP & 3PH MOTOR ASSEMBLY
$3,503.50
$2,794.96
4” FPS 4400 Tri-Seal Submersible PUMP & 3W 1PH MOTOR ASSEMBLY - PMA WITH 1PH CONTROL BOX
Available to Order
Franklin
4” FPS 4400 Tri-Seal Submersible PUMP & 3W 1PH MOTOR ASSEMBLY - PMA WITH 1PH CONTROL BOX
$3,157.00
$2,316.70
Load more products

Bore Pumps for Groundwater, Irrigation and Water Supply

Bore Pumps are designed to lift groundwater from bores and deep wells for irrigation, household water supply, livestock watering and rural applications. Most are installed below the water level, allowing them to push water efficiently to the surface and into tanks, pressure systems or irrigation networks.

Choosing the Right Bore Pump

The right bore pump depends on bore depth, required flow rate, total head and the pressure needed at the outlet. A small domestic system will have different requirements from a large irrigation setup or stock-watering system. It is also important to consider the bore yield so the pump does not draw water faster than the source can recover.

Common Bore Pump Types and Components

This category includes submersible bore pumps, pump motors and related control equipment from brands such as Grundfos, Lowara, Franklin Electric and Pentair. A complete installation may also include starter boxes, pressure controllers, pressure tanks, non-return valves, bore caps, cables and suitable pipework.

Compatibility with Your Water System

Compatibility matters across the whole Bore Pump setup. The pump diameter must suit the bore casing, while the motor, electrical supply and controls need to match the installation. Pipe size, system pressure and irrigation demand should also be considered so the pump can deliver water efficiently without unnecessary restriction.

Avoid Low Flow and Pump Damage

An incorrectly sized bore pump can cause low pressure, poor irrigation performance or excessive cycling. Oversizing can also create problems if the bore cannot supply enough water. Dry running, incorrect controls and unsuitable pipework can shorten pump life, so matching the pump to the bore and system requirements is important.

Get Help Choosing Bore Pumps

The Irrigation Hub stocks Bore Pumps for domestic, agricultural and irrigation applications. If you are unsure which model suits your bore depth, flow or pressure requirements, contact our team for practical advice before ordering.

Not sure which product?

Our irrigation experts are here to help!

Regardless of your specific needs, our irrigation experts are here to help! Drop us a line, or visit us in store to get advice tailored to you.

Chat with a team member
Call 1300 474 482
A woman in a store stands beside a selection of irrigation products, prepared to provide expert guidance to shoppers.
View all

Insights & tips

Get the most out of your bore pump setup with our helpful guides

Find practical guidance on choosing bore pumps for irrigation, household water, livestock and rural applications. Our guides explain how bore depth, flow, head and pressure affect performance, helping you select reliable pumping equipment for groundwater and water-supply systems.

Discover more tips & tricks
News
Beginners Guide
Pumps
El Nino Irrigation Audit: Is Your System Ready?
June 19, 20264 min read
El Nino Irrigation Audit: Is Your System Ready?
El Nino has been officially declared in Australia. Don't wait for the first major heatwave to test your agricultural ...
Read more
News
Beginners Guide
Flow & Pressure
Engaging with The Irrigation Hub: Your Questions Answered, Your Needs Met
August 04, 20231 min read
Engaging with The Irrigation Hub: Your Questions Answered, Your Needs Met
We're committed to being more than just a supplier; we're your partner in all things irrigation. Explore, engage, and...
Read more
News
Welcome
Welcome to The Irrigation Hub: Your One-Stop Shop for All Things Irrigation
August 04, 20232 min read
Welcome to The Irrigation Hub: Your One-Stop Shop for All Things Irrigation
Hello and welcome to The Irrigation Hub, Australia's premier online store for all your irrigation and water managemen...
Read more

Still not sure where to start with Bore Pumps?

The team at The Irrigation Hub are here to help!

Our team can help you find the right product for the job, and develop a comprehensive, tailored solution that takes advantage of the latest innovations in irrigation technology.

Visit us in store
Call 1300 474 482

The Irrigation Hub

Unit 1/27 Kingtel Place
Geebung 4034 QLD
Get directions
Monday 7:30 am - 4:00 pm
Tuesday 7:30 am - 4:00 pm
Wednesday 7:30 am - 4:00 pm
Thursday 7:30 am - 4:00 pm
Friday 7:30 am - 4:00 pm

Frequently asked questions

Bore Pumps are used to bring groundwater up from a bore or deep well and deliver it where it is needed. Common applications include garden and agricultural irrigation, livestock watering, household water supply and pressure systems.

Because every bore is different, the pump needs to provide enough flow and pressure for the intended use without drawing water faster than the bore can supply it.

Start with your bore depth, water level, bore yield, required flow and total head. You should also consider pipe size, available power supply and how the water will be used once it reaches the surface.

If you have a bore log, keep it handy. It can provide useful information about the bore depth and water level when selecting the right pump.

Yes. Most Bore Pumps are submersible because operating below the water level allows the pump to push water upwards rather than trying to draw it from a significant depth.

They are commonly used for deeper groundwater applications where reliable flow and pressure are needed for irrigation, domestic water or rural properties.

Yes. Bore Pumps can supply sprinklers, drip irrigation, garden watering and larger agricultural irrigation systems, provided the pump is correctly matched to the system.

The important part is checking how much water and pressure your irrigation requires. Sprinkler numbers, irrigation zones, elevation changes and pipework can all affect the pump size you need.

We have a wide selection of robust bore pumps from reputable pump manufacturers such as Grundfos, Lowara, Franklin Electric and Pentair. These manufacturers are frequently relied upon in applications where toughness and efficiency are required.

For further advice about which pump brand is appropriate for your bore, get in touch with us and we will be able to assist you in making comparisons.



The Irrigation Hub offers Bore Pumps from Grundfos, Lowara, Franklin and Pentair, covering a wide range of bore depths, flow rates and pressure requirements.

Rather than choosing by brand alone, compare the pump's performance against your bore depth, water supply and required flow. If you are unsure, our team can help you narrow down the right option.
